Xilence XP650R12 650W Full Wired 80 Plus Gold

Series: Gaming GOLD

Achievement: Total 650 W

+12V Total: 650 W

+3.3V/+5V Total: 100 W

Efficiency: Minimum: 90%, Maximum: 93%

Input: 200-240 volts

Standard: ATX12V 2.52

Construction: ATX

Certification: 80 PLUS Gold

• Currents:
• +3.3 V: 20 A
• +5 V: 20 A
• +5 Vsb: 3 A
• -12 V: 0.3 A
• +12 V Total: 54.1 A
• +12 V1: 54.1 A

Power Factor Correction: Active PFC

Switch: 1x Power Switch

• Connections:
• 1x 24-pin ATX12V-2.x
• 1x 4+4-pin 12V
• 3x 4-pin 5.25″
• 3x 6+2-pin graphics
• 1x 8-pin 12V
• 6x 15-pin SATA

Cooling:

• Number of fans: 1x 120 mm fan
• Regulation: Temperature-controlled
• Volume: 9.9 dB(A) at 20% load, 10.4 dB(A) at 50% load, 35.8 dB(A) at 100% load

Protection:

• Current Spike Protection (OCP)
• Surge Protection (OVP)
• Undervoltage Protection (UVP)
• Overload Protection (OLP/OPP)
• Short Circuit Protection (SCP)
• Overheat Protection (OTP)
